Push button tact switch module
This content will be shared across all product pages.
Description:
The Push Button Tact Switch Module is a simple and efficient component designed for various applications requiring tactile feedback. This module features a push button switch mounted on a PCB, making it easy to integrate into electronic circuits and development projects. It is ideal for use in user interfaces, control panels, and custom electronic projects.
Key Features:
- Tactile Feedback: Provides a satisfying click when pressed.
- Compact Design: Small size for easy integration into projects.
- Easy Mounting: Pre-soldered on a PCB for straightforward installation.
- High Durability: Built to withstand numerous presses.
- Versatile Applications: Suitable for a wide range of electronic projects.
- Type: Tactile Push Button Switch
- Operating Voltage: Typically 3.3V to 5V
- Contact Resistance: Low resistance for reliable operation
- Mechanical Life: High durability with long lifespan
- Dimensions: Compact size for easy integration
- User Interfaces: Buttons for control panels and input devices.
- Development Projects: Ideal for prototyping and testing.
- Consumer Electronics: Used in remote controls, calculators, and more.
- DIY Projects: Suitable for hobbyist and custom electronic applications.
- Industrial Controls: For use in machinery and equipment interfaces.s
Technical Specifications:
- Logic Family: CMOS
- Number of Channels: 3
- Switch Configuration: Single-Pole Double-Throw (SPDT)
- Supply Voltage Range: 3V to 15V
- “ON” Resistance (R_ON): 125Ω typical at V_DD = 10V
- “OFF” Leakage Current (I_OFF): ±100pA typical at V_DD = 10V
- Control Input Voltage (V_IH): 0.7 V_DD min, 0.3 V_DD max
- Maximum Operating Frequency: 40 MHz at V_DD = 10V
Applications:
- Signal routing and switching
- Analog and digital multiplexing
- Audio and video signal processing
- Data acquisition systems
- Test equipment
