5000W 220V Thyristor
This content will be shared across all product pages.
Description:
The 5000W 220V Thyristor is a high-power semiconductor device designed to control and switch high voltage and current in various industrial and power electronics applications. This thyristor can handle significant power loads, making it suitable for use in AC and DC control circuits where precise power management is required.
Key Features:
- High Power Rating: Capable of handling up to 5000 watts of power.
- Voltage Rating: Designed for operation at 220V AC.
- Efficient Switching: Provides reliable and efficient switching for high-power applications.
- Robust Construction: Built to withstand high voltages and currents with durability.
- Power Rating: 5000W
- Voltage Rating: 220V AC
- Current Rating: Refer to datasheet for exact current handling capabilities
- Control Method: Typically gate-controlled for precise switching
- Package Type: Refer to datasheet for package details
- Power Control: Used in high-power AC and DC control circuits for managing large loads.
- Industrial Equipment: Ideal for use in industrial machinery and power systems.
- Heater Control: Suitable for controlling heating elements and other high-power devices.
- Light Dimming: Can be used in dimmer circuits for lighting systems.
Technical Specifications:
- Logic Family: CMOS
- Number of Channels: 3
- Switch Configuration: Single-Pole Double-Throw (SPDT)
- Supply Voltage Range: 3V to 15V
- “ON” Resistance (R_ON): 125Ω typical at V_DD = 10V
- “OFF” Leakage Current (I_OFF): ±100pA typical at V_DD = 10V
- Control Input Voltage (V_IH): 0.7 V_DD min, 0.3 V_DD max
- Maximum Operating Frequency: 40 MHz at V_DD = 10V
Applications:
- Signal routing and switching
- Analog and digital multiplexing
- Audio and video signal processing
- Data acquisition systems
- Test equipment
