FZ25 Electronic load
This content will be shared across all product pages.
Description:
The FZ25 Electronic Load is a versatile and precise device designed for testing and evaluating power sources and electronic components. It allows for the controlled application of load conditions, enabling users to simulate various scenarios and measure performance characteristics such as voltage, current, power, and resistance. This electronic load is suitable for applications in battery testing, power supply evaluation, and general electronic testing and development.
Key Features:
- Wide input voltage and current range
- Multiple operating modes: constant current (CC), constant voltage (CV), constant resistance (CR), and constant power (CP)
- High precision and stability
- LCD display for real-time monitoring of parameters
- User-friendly interface with easy-to-navigate controls
- Overcurrent, overvoltage, overpower, and thermal protection
- Cooling fan for thermal management and extended operation
- Compact and robust design for bench-top use
- Input Voltage Range: Typically 0V to 150V
- Input Current Range: Typically up to 25A
- Power Dissipation: Up to 250W
- Operating Modes: CC, CV, CR, CP
- Display: LCD for voltage, current, power, and resistance readings
- Protection Features: Overcurrent, overvoltage, overpower, thermal protection
- Cooling: Active cooling with built-in fan
- Dimensions: Compact size for laboratory and workshop use
- Weight: Lightweight for portability
- Battery testing and characterization
- Power supply and converter evaluation
- Testing of electronic components and modules
- Load simulation in development and production environments
- General electronic testing and troubleshooting
Technical Specifications:
- Logic Family: CMOS
- Number of Channels: 3
- Switch Configuration: Single-Pole Double-Throw (SPDT)
- Supply Voltage Range: 3V to 15V
- “ON” Resistance (R_ON): 125Ω typical at V_DD = 10V
- “OFF” Leakage Current (I_OFF): ±100pA typical at V_DD = 10V
- Control Input Voltage (V_IH): 0.7 V_DD min, 0.3 V_DD max
- Maximum Operating Frequency: 40 MHz at V_DD = 10V
Applications:
- Signal routing and switching
- Analog and digital multiplexing
- Audio and video signal processing
- Data acquisition systems
- Test equipment
