GY-906 MLX90614 non contact temperature sensor module{}+
This content will be shared across all product pages.
The GY-906 MLX90614 Non-Contact Temperature Sensor Module is a highly accurate infrared thermometer designed for non-contact temperature measurements. This module uses the MLX90614 sensor, which can measure the temperature of objects without physical contact. It is ideal for applications such as industrial temperature monitoring, medical thermometers, home automation, and DIY electronics projects. The module provides both digital and analog outputs, making it easy to interface with microcontrollers and other digital devices.
Key Features:
- High accuracy non-contact temperature measurement
- Measures object and ambient temperature
- Digital output (I2C and PWM) and analog output
- Wide temperature measurement range
- Compact and easy to integrate into various projects
- Low power consumption
- Suitable for a variety of applications
- Sensor Type: MLX90614 infrared thermometer
- Temperature Measurement Range: -70°C to +380°C for object temperature, -40°C to +85°C for ambient temperature
- Output: Digital (I2C, PWM) and analog voltage
- Power Supply: 3.3V to 5V DC
- Operating Temperature: -40°C to +85°C
- Industrial temperature monitoring
- Medical thermometers
- Home automation
- HVAC systems
- DIY electronics projects
- Consumer electronics
Technical Specifications:
- Logic Family: CMOS
- Number of Channels: 3
- Switch Configuration: Single-Pole Double-Throw (SPDT)
- Supply Voltage Range: 3V to 15V
- “ON” Resistance (R_ON): 125Ω typical at V_DD = 10V
- “OFF” Leakage Current (I_OFF): ±100pA typical at V_DD = 10V
- Control Input Voltage (V_IH): 0.7 V_DD min, 0.3 V_DD max
- Maximum Operating Frequency: 40 MHz at V_DD = 10V
Applications:
- Signal routing and switching
- Analog and digital multiplexing
- Audio and video signal processing
- Data acquisition systems
- Test equipment
