MJ15025G triode audio power amplifier
This content will be shared across all product pages.
Description: The MJ15025G is a high-power NPN silicon transistor designed for use in audio power amplifier and general purpose applications. It is characterized by its high current capability, low distortion, and robust construction, making it suitable for demanding amplifier designs where high fidelity and reliability are essential.
Key Features:
- NPN silicon transistor
- High current capability
- Low distortion
- Excellent safe operating area (SOA)
- Enhanced thermal performance
- Collector-Emitter Voltage (VCEO): 250V
- Collector-Base Voltage (VCBO): 250V
- Collector Current (IC): 16A
- Power Dissipation (Ptot): 250W
- DC Current Gain (hFE): 15 to 150
- Operating Temperature Range: -65°C to +200°C
- Package Type: TO-3
- Audio power amplifiers
- High-power linear applications
- Switching regulators
- Power supplies
Technical Specifications:
- Logic Family: CMOS
- Number of Channels: 3
- Switch Configuration: Single-Pole Double-Throw (SPDT)
- Supply Voltage Range: 3V to 15V
- “ON” Resistance (R_ON): 125Ω typical at V_DD = 10V
- “OFF” Leakage Current (I_OFF): ±100pA typical at V_DD = 10V
- Control Input Voltage (V_IH): 0.7 V_DD min, 0.3 V_DD max
- Maximum Operating Frequency: 40 MHz at V_DD = 10V
Applications:
- Signal routing and switching
- Analog and digital multiplexing
- Audio and video signal processing
- Data acquisition systems
- Test equipment
