Male USB B-type module
This content will be shared across all product pages.
The Male USB B-type Module is a versatile and reliable connector module designed for use in a variety of electronic projects and applications. It features a standard USB Type-B male connector, commonly found in printers, scanners, and other peripheral devices. This module is ideal for creating custom USB cables or for integrating USB connectivity into DIY projects and prototypes.
Key Features:
- USB Type-B Male Connector
- Durable and reliable construction
- Easy to solder and integrate into custom circuits
- Standard USB 2.0 compatibility
- Compact design for efficient use of space
- RoHS compliant
- Connector Type: USB Type-B Male
- USB Standard: USB 2.0
- Maximum Data Transfer Rate: 480 Mbps
- Contact Resistance: ≤30mΩ
- Insulation Resistance: ≥100MΩ
- Operating Temperature Range: -25°C to +85°C
- Shell Material: Nickel-plated brass
- Insulator Material: High-temperature thermoplastic
- Custom USB Cable Assemblies
- DIY Electronics Projects
- Prototyping USB Devices
- Integrating USB Connectivity in Embedded Systems
- Connecting Peripheral Devices to Microcontrollers
- Educational and Hobbyist Projects
Technical Specifications:
- Logic Family: CMOS
- Number of Channels: 3
- Switch Configuration: Single-Pole Double-Throw (SPDT)
- Supply Voltage Range: 3V to 15V
- “ON” Resistance (R_ON): 125Ω typical at V_DD = 10V
- “OFF” Leakage Current (I_OFF): ±100pA typical at V_DD = 10V
- Control Input Voltage (V_IH): 0.7 V_DD min, 0.3 V_DD max
- Maximum Operating Frequency: 40 MHz at V_DD = 10V
Applications:
- Signal routing and switching
- Analog and digital multiplexing
- Audio and video signal processing
- Data acquisition systems
- Test equipment
