STK0706 600v 7A FET
This content will be shared across all product pages.
Description: The STK0706 is an N-channel power MOSFET designed for high voltage and high current switching applications. With a voltage rating of 600V and a current rating of 7A, this MOSFET is ideal for use in power supplies, inverters, motor drives, and other applications requiring efficient and reliable high-voltage switching. The STK0706 offers low on-resistance and fast switching capabilities, ensuring high performance in demanding environments.
Key Features:
- N-channel enhancement mode power MOSFET
- High voltage and current handling capability
- Low on-resistance for high efficiency
- Fast switching speed
- Rugged and reliable design
- RoHS compliant
- Drain-Source Voltage (V_DS): 600V
- Continuous Drain Current (I_D): 7A
- Pulsed Drain Current (I_DM): 28A
- Gate-Source Voltage (V_GS): ±30V
- On-Resistance (R_DS(on)): 1.4Ω (max) at V_GS = 10V, I_D = 3.5A
- Total Gate Charge (Q_g): 32nC (typical)
- Rise Time (t_r): 10ns
- Fall Time (t_f): 9ns
- Package Type: TO-220
- Power supplies
- Inverters
- Motor drives
- High-voltage switching
- Industrial equipment
Technical Specifications:
- Logic Family: CMOS
- Number of Channels: 3
- Switch Configuration: Single-Pole Double-Throw (SPDT)
- Supply Voltage Range: 3V to 15V
- “ON” Resistance (R_ON): 125Ω typical at V_DD = 10V
- “OFF” Leakage Current (I_OFF): ±100pA typical at V_DD = 10V
- Control Input Voltage (V_IH): 0.7 V_DD min, 0.3 V_DD max
- Maximum Operating Frequency: 40 MHz at V_DD = 10V
Applications:
- Signal routing and switching
- Analog and digital multiplexing
- Audio and video signal processing
- Data acquisition systems
- Test equipment
