1.5m Big Audio Jack Extender
This content will be shared across all product pages.
The 1.5m Big Audio Jack Extender is a high-quality extension cable designed to extend the reach of your audio connections. It features a 3.5mm male-to-female jack, allowing you to easily connect your audio devices over a longer distance. This extender is ideal for use with headphones, speakers, car audio systems, and other audio equipment.
Key Features:
- Cable Length: 1.5 meters (approximately 5 feet)
- Connector Type: 3.5mm male to 3.5mm female
- High-Quality Construction: Durable materials ensure a stable connection and long-lasting performance
- Gold-Plated Connectors: Provide better conductivity and reduce signal loss
- Flexible Design: The cable is designed to be flexible and easy to route
- Cable Length: 1.5 meters
- Connector Type: 3.5mm male to 3.5mm female
- Conductor Material: Copper
- Connector Material: Gold-plated for enhanced signal quality
- Cable Jacket: PVC for durability and flexibility
- Impedance: 75 Ohms
- Frequency Response: 20Hz - 20kHz
- Shielding: Double shielding to minimize interference
- Operating Temperature: -20°C to +60°C (-4°F to +140°F)
- Weight: Approximately 50g
- Headphones: Extend the reach of your headphones for more comfortable listening.
- Speakers: Connect speakers that are further away from your audio source.
- Car Audio Systems: Extend the audio cable in your car for better accessibility.
- Home Audio Systems: Use it to connect various audio devices in your home setup.
Technical Specifications:
- Logic Family: CMOS
- Number of Channels: 3
- Switch Configuration: Single-Pole Double-Throw (SPDT)
- Supply Voltage Range: 3V to 15V
- “ON” Resistance (R_ON): 125Ω typical at V_DD = 10V
- “OFF” Leakage Current (I_OFF): ±100pA typical at V_DD = 10V
- Control Input Voltage (V_IH): 0.7 V_DD min, 0.3 V_DD max
- Maximum Operating Frequency: 40 MHz at V_DD = 10V
Applications:
- Signal routing and switching
- Analog and digital multiplexing
- Audio and video signal processing
- Data acquisition systems
- Test equipment
