Pic kit3 with zif adapter

https://www.hub360.cc/web/image/product.template/13805/image_1920?unique=32986b9
(0 review)
14 sold in last 24 hours

₦ 38,418.60 38418.6 NGN ₦ 38,418.60 Tax Excluded

₦ 41,300.00 Tax Excluded

Not Available For Sale

(₦ 0.00 / Units)
5 people are viewing this right now

This combination does not exist.

This content will be shared across all product pages.

Contact Us
The PICkit 3 with ZIF Adapter is a programmer and debugger tool designed for use with Microchip's PIC microcontrollers and dsPIC Digital Signal Controllers (DSCs). The PICkit 3 offers an easy and reliable way to program and debug PIC microcontrollers directly from the MPLAB IDE software. The included ZIF (Zero Insertion Force) adapter enhances the usability by providing a convenient and secure way to insert and remove microcontroller chips without damaging the pins, making it ideal for frequent programming and development tasks. Key Features:
  • Supports a wide range of PIC microcontrollers and dsPIC DSCs
  • Direct connection to the MPLAB IDE software for programming and debugging
  • USB connectivity for easy interface with a computer
  • Real-time execution and debugging capabilities
  • Integrated ZIF adapter for easy chip insertion and removal
  • Compact and portable design
Technical Specifications:
  • Programmer Type: In-Circuit Debugger (ICD) and Programmer
  • Connectivity: USB 2.0 interface
  • Supported Devices: Wide range of PIC microcontrollers and dsPIC DSCs
  • Programming Voltage: 2.0V to 5.5V
  • Debugging Features: Real-time execution, breakpoints, single-step, and variable inspection
  • ZIF Adapter: 28-pin socket for easy insertion and removal of chips
  • Dimensions: Typically 95mm x 62mm x 25mm (programmer), 80mm x 30mm x 20mm (ZIF adapter)
Applications:
  • Development and prototyping with PIC microcontrollers
  • Educational purposes and learning about microcontroller programming
  • Firmware debugging and testing
  • Programming PIC microcontrollers for embedded systems and projects
Usage:
  1. Connect the PICkit 3 to your computer via the USB cable.
  2. Install the necessary drivers and MPLAB IDE software from Microchip’s website.
  3. Insert the PIC microcontroller into the ZIF adapter, ensuring correct orientation.
  4. Connect the ZIF adapter to the PICkit 3 programmer.
  5. Open the MPLAB IDE software and configure the programmer settings.
  6. Program and debug your PIC microcontroller using the MPLAB IDE interface.
Caution:
  • Ensure correct orientation of the microcontroller in the ZIF adapter to avoid damaging the pins.
  • Follow the recommended voltage levels and programming guidelines provided by Microchip.
  • Handle the PICkit 3 and ZIF adapter carefully to prevent static discharge and physical damage.
Datasheet: For detailed technical specifications, refer to the PICkit 3 with ZIF Adapter Datasheet.

Technical Specifications:

  • Logic Family: CMOS
  • Number of Channels: 3
  • Switch Configuration: Single-Pole Double-Throw (SPDT)
  • Supply Voltage Range: 3V to 15V
  • “ON” Resistance (R_ON): 125Ω typical at V_DD = 10V
  • “OFF” Leakage Current (I_OFF): ±100pA typical at V_DD = 10V
  • Control Input Voltage (V_IH): 0.7 V_DD min, 0.3 V_DD max
  • Maximum Operating Frequency: 40 MHz at V_DD = 10V

Applications:

  • Signal routing and switching
  • Analog and digital multiplexing
  • Audio and video signal processing
  • Data acquisition systems
  • Test equipment
