Description
The 10-Pin Female Header (2.54mm Pitch) is a reliable connector designed for board-to-board and module-to-board connections in electronic circuits. It is commonly paired with male breakaway headers for stacking or interconnecting PCBs. With a standard 2.54mm pitch and through-hole design, it ensures strong solder joints and easy integration into breadboards and prototyping systems. This header is ideal for connecting sensors, modules, and peripherals to microcontroller boards such as Arduino, Raspberry Pi, and ESP32.
Key Features
- Standard 10-Pin Configuration: Ideal for multi-signal or modular connections
- 2.54mm Pitch: Fully compatible with standard prototyping boards and PCBs
- Through-Hole Mounting: Provides stable mechanical support and easy soldering
- Square Contacts: Ensures consistent and durable electrical connections
- Compact and Durable Design: Suitable for repeated insertions and long-term projects
Specification
- Contact Type: Female
- Number of Pins: 10
- Contact Shape: Square
- Mounting Type: Through-hole
- Pitch: 2.54mm
- Insulation Height: 8.51mm (typical)
- Material: Plastic housing with metal contacts
- Compatibility: Works with standard male headers and jumper wire connectors
Application
- Board-to-Board Connections: For stacking or linking multiple PCBs
- Prototyping & Breadboarding: Enables quick and reusable connections during development
- Microcontroller Interfaces: Connects shields, modules, and peripherals to Arduino, Raspberry Pi, ESP32, and other boards
- Custom Cable Assemblies: Acts as a connector endpoint for jumper wires and custom wiring harnesses.
