Description
The Blynk IoT Heart Rate and Oxygen Monitor Kit is an Internet of Things (IoT)–based health monitoring project that measures real-time pulse rate and blood oxygen (SpO₂) levels using the MAX30100 sensor. The readings are processed by an ESP32 microcontroller and transmitted to the Blynk mobile application for remote monitoring. This project introduces learners to biomedical sensing, IoT communication, and data visualization through cloud platforms.
Key Features
- Real-time monitoring: Continuously measures heart rate and oxygen saturation (SpO₂).
- Cloud connectivity: Sends data to the Blynk IoT app for live display and remote tracking.
- Wireless communication: Utilizes ESP32’s built-in Wi-Fi module for seamless data transmission.
- Compact and efficient design: Requires minimal wiring using jumper wires for quick setup.
- Arduino-compatible: Easy to program, modify, and integrate with other IoT systems.
- Ideal for health-tech learning: Demonstrates practical applications of sensors in IoT.
Specification
- Microcontroller: ESP32 Development Board
- Sensor: MAX30100 Pulse Oximeter and Heart Rate Sensor
- Connectivity: Wi-Fi via ESP32
- Prototyping Components: Jumper Wires and Breadboard (optional)
- Power Supply: 3.3V–5V USB or external regulated adapter
- Software Platform: Blynk IoT Application
Application
Perfect for IoT and biomedical innovation projects, this kit can be used in:
- Remote health monitoring systems
- IoT and cloud-based data logging experiments
- Biomedical sensor interfacing and signal analysis training
-
Smart health device prototypes and STEM education
