STC12C5A60S2-35I-LQFP44
The STC12C5A60S2-35I-LQFP44 is a microcontroller from STC Microelectronics, based on the 8051 architecture. It is designed for embedded control applications requiring moderate processing power and integrated peripherals. The STC12C5A60S2-35I-LQFP44 features a compact design with integrated flash memory, EEPROM, timers/counters, UART, and GPIO pins, making it suitable for a wide range of industrial, consumer, and automotive applications.
Key Features:
- Microcontroller Core: 8051-compatible
- Clock Speed: Up to 35 MHz
- Program Memory: 60 KB Flash
- Data Memory: 2 KB RAM
- EEPROM: 2 KB
- I/O Pins: Up to 34 GPIO pins
- Communication Interfaces: UART, SPI, I2C
- Analog-to-Digital Converter (ADC): Integrated ADC for analog signal acquisition
- Operating Voltage: 2.4V to 5.5V
- Package Type: LQFP-44 (Low-profile Quad Flat Package)
- CPU: 8-bit 8051-compatible
- Operating Frequency: Up to 35 MHz
- Program Memory Size: 60 KB Flash
- Data Memory Size: 2 KB RAM, 2 KB EEPROM
- I/O Pins: Up to 34 GPIO pins
- Communication Interfaces: UART, SPI, I2C
- Analog-to-Digital Converter (ADC): Integrated ADC with multiple channels
- Supply Voltage: 2.4V to 5.5V
- Package Type: LQFP-44
- Industrial Automation: Control systems, monitoring devices, and sensors.
- Consumer Electronics: Remote controls, home appliances, and small displays.
- Automotive: Dashboard controls, sensor interfaces, and motor control.
- Smart Devices: IoT devices, wearable electronics, and embedded systems.
- Communications: Modems, network devices, and interface controllers.
