ADC0809CCN 8bit ADC
Description:
The ADC0809CCN is an 8-bit analog-to-digital converter (ADC) with an 8-channel multiplexer, designed to convert analog signals into digital data. It integrates an 8-bit successive approximation ADC with a multiplexer and control logic, providing a complete data acquisition system. The ADC0809CCN is widely used in applications requiring accurate and reliable analog-to-digital conversion, such as data logging, instrumentation, and process control.
Key Features:
- 8-bit resolution
- 8-channel multiplexer
- Successive approximation conversion
- High speed: conversion time of 100 µs
- Low power consumption
- Easy interface with microcontrollers
- Wide operating voltage range: 2.5V to 6.3V
- Single supply operation
- TTL and CMOS compatible
- Package Type: PDIP-28
- Resolution: 8 bits
- Number of Channels: 8
- Conversion Time: 100 µs (typical)
- Analog Input Voltage Range: 0V to Vcc
- Supply Voltage Range: 2.5V to 6.3V
- Operating Temperature Range: 0°C to +70°C
- Digital Output: Parallel 8-bit
- Dimensions: 35.56 mm x 7.62 mm x 3.81 mm
- Weight: 1.5 g
- Data Acquisition Systems: Converts analog signals to digital data for processing and analysis.
- Instrumentation: Used in various measurement and instrumentation applications.
- Process Control: Provides accurate analog-to-digital conversion in industrial control systems.
- Embedded Systems: Ideal for microcontroller-based projects requiring analog signal input.
- Medical Devices: Used in medical equipment for precise analog-to-digital conversion.
- Consumer Electronics: Integrated into devices requiring digital representation of analog signals.
