The DC-DC USB Adjustable Buck-Boost Converter is designed to provide a stable and adjustable output voltage from a USB power source. It features a seven-segment display for real-time monitoring of input and output voltages. This converter supports both step-up (boost) and step-down (buck) operations, making it suitable for a wide range of electronic applications.
Key Features:
- Input Voltage Range: 5V.
- Adjustable Output Voltage: Allows for adjustment of output voltage from 3.3V to 24V.
- Buck-Boost Conversion: Capable of boosting or bucking the input voltage as required.
- Seven Segment Display: Provides clear and easy-to-read display of input and output voltages.
- High Efficiency: Efficient power conversion with minimal energy loss.
- Compact and Lightweight: Convenient size for various applications.
- Protection Features: Includes over-current, over-voltage, and short-circuit protection.
- Input Voltage Range: 5V
- Output Voltage Range: 3.3V to 24V (adjustable)
- Output Current: Up to 2A (depending on input and output voltage)
- Display Type: Seven Segment Display
- Conversion Efficiency: Up to 92%
- Protection: Over-current, over-voltage, short-circuit protection
- Dimensions: 60mm x 30mm x 20mm
- Weight: 25g
- Portable Power Supplies: Create a portable power supply with adjustable output for various devices.
- DIY Electronics Projects: Ideal for hobbyists and makers requiring different voltage levels.
- Voltage Regulation: Provides a stable voltage output for electronics and prototypes.
- Battery Management: Useful in battery-powered projects for voltage adjustment and regulation.
- Testing and Prototyping: Facilitates testing and prototyping with adjustable voltage needs.
