S2513 thyristor

https://www.hub360.cc/web/image/product.template/14683/image_1920?unique=5719fb0
(0 review)

₦ 3,700.00 3700.0 NGN ₦ 3,700.00

₦ 3,700.00

Not Available For Sale

(₦ 0.00 / Units)

This combination does not exist.

Contact Us
The S2513 is a general-purpose silicon-controlled rectifier (SCR) designed for use in a wide variety of applications where reliable switching and control of AC and DC loads is required. This thyristor is capable of handling moderate current and voltage levels, making it suitable for applications in light dimming, motor control, and power switching. Key Features:
  • High blocking voltage: 600V
  • Medium current handling capability: 25A RMS
  • Sensitive gate trigger current
  • Standard TO-220 package
Technical Specifications:
  • Repetitive Peak Off-State Voltage (Vdrm): 600V
  • Repetitive Peak Reverse Voltage (Vrrm): 600V
  • RMS On-State Current (It(RMS)): 25A
  • Peak Non-Repetitive Surge Current (Itsm): 250A (50Hz), 262A (60Hz)
  • Gate Trigger Current (Igt): 3-15mA
  • Holding Current (Ih): 20mA
  • On-State Voltage (Vtm): 1.6V
  • Operating Temperature Range: -40°C to +125°C
  • Package: TO-220
Applications:
  • Light dimmers
  • Motor speed controls
  • Heating control systems
  • Static switching
  • AC switch
  • Industrial and domestic lighting
