SN74LS194AN (74LS194) register
Description:
The SN74LS194AN is a 4-bit bidirectional universal shift register IC, capable of shifting data in both directions (left and right) based on control inputs. It features a parallel load capability where data can be loaded into the register asynchronously. This IC is commonly used in digital systems for various applications such as data storage, serial-to-parallel conversion, parallel-to-serial conversion, and arithmetic operations involving shifts.
Key Features:
- 4-bit bidirectional shift register
- Parallel load capability for synchronous loading of data
- Shift left (SL), shift right (SR), and shift/load (S/L) control inputs
- Serial (SER) input for serial data entry
- Asynchronous clear (CLR) input for resetting the register
- TTL compatible inputs and outputs
- Edge-triggered for synchronous operation
- Package Type: 16-pin DIP (Dual In-line Package)
- Supply Voltage (VCC): 4.75V to 5.25V
- Input Voltage (VIN): 0V to VCC
- Output Voltage (VOUT): 0V to VCC
- Input High Voltage (VIH): 2V (min) at VCC = 5V
- Input Low Voltage (VIL): 0.8V (max) at VCC = 5V
- Output Current (IOH, IOL): ±8 mA (max)
- Quiescent Supply Current (ICC): 4 mA (typical) at VCC = 5V
- Operating Temperature Range: 0°C to +70°C
- Serial-to-parallel conversion
- Parallel-to-serial conversion
- Data storage and transfer in microprocessor systems
- Arithmetic operations involving shifts (multiplication/division by powers of 2)
- Control and timing applications in digital circuits
