Description:
The DS0026CN is a precision monostable multivibrator (one-shot) IC designed for applications requiring precise timing and pulse generation. It produces a single output pulse in response to an input trigger signal, with accurate timing characteristics ideal for various timing and control applications.
Key Features:
- Precision monostable multivibrator
- Adjustable pulse width via external timing components
- Triggerable from a variety of sources
- Fast output rise and fall times
- Wide supply voltage range
- TTL-compatible logic inputs
- Stable operation over temperature and voltage variations
- Package Type: DIP-14
- Supply Voltage Range: 4.5V to 15V
- Output Pulse Width: Adjustable using external resistors and capacitors
- Trigger Input Voltage: TTL compatible
- Operating Temperature Range: 0°C to +70°C
- Dimensions: 19.3 mm x 6.35 mm x 3.3 mm
- Weight: 0.32 g
- Timing and Delay Generators: Used in pulse shaping and delay circuits.
- Precision Timing: Provides accurate timing signals for instrumentation and control systems.
- Pulse Generation: Generates precise pulses for triggering other circuits and devices.
- Frequency Synthesis: Used in clock and timing circuits for frequency synthesis.
- Measurement Equipment: Provides timing references for measurement and testing applications.
