SG3524N switching power supply
Product Name: SG3524N Switching Power Supply Controller
Description:
The SG3524N is a versatile pulse width modulation (PWM) control IC designed for use in switching power supply applications. It provides all the necessary functions for a basic flyback, boost, or buck converter circuit, making it suitable for various power supply designs. The SG3524N features adjustable frequency and duty cycle control, allowing for efficient power management and regulation.
Key Features:
- Wide input voltage range
- Adjustable switching frequency
- Adjustable duty cycle
- Error amplifier with precise voltage reference
- Pulse-by-pulse current limiting
- Soft start capability
- Output drivers for external MOSFETs or BJTs
- Protection features: overvoltage, overcurrent, and overtemperature protection
- Package Type: PDIP-16, SOIC-16
- Supply Voltage Range: 8V to 40V
- Operating Temperature Range: 0°C to +70°C
- Frequency Range: Adjustable, typically up to 500 kHz
- Duty Cycle Range: Adjustable, typically up to 50%
- Dimensions: Compact and suitable for various circuit designs
- Switching Power Supplies
- DC-DC Converters
- Battery Chargers
- LED Drivers
- Inverters
- Industrial Power Systems
