0.5 inches 2 digit seven segment
The 0.5 inches 2-digit seven-segment display is an electronic display device used to show numerical information. It consists of two individual seven-segment displays integrated into a single unit, making it ideal for compact digital readouts in various applications. The segments can be independently controlled to display digits from 0 to 9.
Key Features:
- 0.5-inch digit height
- Dual-digit display for compact numerical readout
- Common anode or common cathode configuration (specify as needed)
- Bright and clear LED segments
- Low power consumption
- Easy to interface with microcontrollers and other digital circuits
- Long-lasting and durable
- Display Type: Seven-segment
- Digit Height: 0.5 inches
- Number of Digits: 2
- Segment Color: Red (other colors available upon request)
- Common Configuration: Common anode or common cathode
- Forward Voltage: Typically 1.8V - 2.2V per segment
- Forward Current: 10mA - 20mA per segment
- Power Dissipation: 100mW per segment
- Operating Temperature Range: -40°C to +85°C
- Package Type: Through-hole or surface-mount
- Digital Clocks: Displaying time in hours and minutes
- Counters and Timers: Numerical output for counting events or timing intervals
- Temperature Displays: Showing temperature readings from sensors
- Electronic Meters: Readouts for voltmeters, ammeters, and other measuring instruments
- Consumer Electronics: Numeric display in devices such as microwaves and ovens
- Determine the common configuration (anode or cathode) and ensure compatibility with your circuit.
- Connect the appropriate pins to the microcontroller or driver circuit.
- Configure the software to control each segment individually for displaying the desired digits.
- Test the display to ensure all segments light up correctly and display the numbers as expected.
- Verify the voltage and current ratings to prevent damage to the display.
- Handle with care to avoid physical damage to the segments or leads.
- Ensure proper current limiting resistors are used to protect the LEDs.
