502 5KΩ potentiometer/variable resistor
The 502 5KΩ potentiometer is a variable resistor that offers adjustable resistance up to 5,000 ohms. It features a rotary knob for precise control over resistance values, making it ideal for applications requiring fine-tuning, calibration, and adjustment. This potentiometer is commonly used in various electronic devices for volume control, tuning, and calibration.
Key Features:
- Adjustable resistance from 0Ω to 5kΩ
- Rotary knob for smooth and accurate adjustment
- Compact and durable design
- Suitable for a range of electronic applications including calibration and tuning
- Typically used for volume controls and adjustable settings in devices
- Resistance Range: 0Ω to 5kΩ (5,000Ω)
- Resistance Tolerance: ±20% (standard tolerance; may vary by manufacturer)
- Power Rating: Typically 0.5W to 1W (check specific datasheet for exact power rating)
- Temperature Coefficient: ±100 ppm/°C (typical)
- Adjustable Type: Rotary
- Mounting Type: Through-hole or surface mount (depends on the variant)
- Dimensions: Varies by manufacturer; generally around 10mm to 20mm in diameter
- Volume Control: Adjusts sound levels in audio equipment, such as amplifiers and mixers.
- Calibration: Ideal for precise adjustments in electronic circuits and devices.
- Tuning: Allows for fine-tuning of circuit parameters where variable resistance is needed.
- Adjustable Controls: Provides variable resistance for user interfaces and control systems.
- Connect the three terminals of the potentiometer to the circuit where adjustable resistance is required.
- Rotate the knob to adjust the resistance value according to your needs.
- Ensure correct handling and adjustment to prevent damage to the potentiometer or the circuit.
- Do not exceed the rated power or voltage specifications to avoid damage.
- Handle the potentiometer carefully to ensure smooth operation and longevity.
