SHTC3 Temperature and Humidity Sensor
The SHTC3 is a digital temperature and humidity sensor designed for high-accuracy environmental monitoring in compact and power-efficient applications. It features a fully calibrated sensing element with a digital I²C interface, making it ideal for smart devices, wearables, and battery-operated systems.
Key Features:
- Dual Measurement: Temperature and relative humidity
- High Accuracy: ±2% RH, ±0.2°C typical
- I²C Interface: Simple digital communication
- Low Power: Optimized for battery operation
- Fully Calibrated: No external components needed
- Compact Design: Fits into space-constrained designs
- Model: SHTC3
- Temperature Range: -40°C to +125°C
- Humidity Range: 0% to 100% RH
- Temperature Accuracy: ±0.2°C (typical)
- Humidity Accuracy: ±2% RH (typical)
- Operating Voltage: 1.62V – 3.6V
- Current Consumption: 0.5 µA (sleep), 450 µA (measurement)
- Interface: I²C (address: 0x70)
- Response Time: <8 seconds
- Module Size: ~15 mm × 10 mm
- Weight: ~1 g
- Wearables and portable electronics
- Smart home devices
- Environmental data logging
- HVAC systems
- IoT environmental monitoring
