35mm Dual-Wall Heat Shrink Tubing – 2:1 Shrink Ratio, Waterproof & Adhesive-Lined
35mm Dual-Wall Heat Shrink Tubing – 2:1 Shrink Ratio, Waterproof & Adhesive-Lined
Product Overview:
Engineered for heavy-duty protection, this 35mm heat shrink tubing delivers both environmental sealing and mechanical reinforcement. Its dual-wall construction—featuring a cross-linked polyolefin outer layer and a heat-activated adhesive lining—ensures a reliable, watertight seal over cables, connectors, and splices in demanding environments.
Key Features:
-
2:1 Shrink Ratio
Reduces to half its original diameter with heat, conforming tightly to irregular shapes and surfaces. -
Dual-Wall Design
Combines a tough outer jacket with an inner thermoplastic adhesive that melts, flows, and solidifies for a permanent seal. -
Waterproof & Pullout Resistant
Seals against water, dust, and debris while offering excellent strain relief and resistance to cable slippage. -
Stress Relief at Bend Points
Ideal for connectors and joints prone to flexing—extends cable life and enhances joint durability.
Technical Specifications:
-
Nominal Diameter (Pre-Shrink): 35mm
-
Shrink Ratio: 2:1
-
Material:
-
Outer Layer: Cross-linked polyolefin
-
Inner Layer: Thermoplastic adhesive
-
-
Shrink Temperature: Begins at ~70°C, full shrink at ~110°C
-
Operating Temperature: -55°C to +125°C
-
Environmental Protection: Waterproof, dustproof, vibration-resistant
Applications:
Recommended for automotive, marine, aerospace, and industrial environments where strong environmental sealing and strain relief are critical.
